- Standard Upper Weights: 38,500lbs (17,463kg)
- Main Transport Load: 99,621lbs (45,187kg)
- Attachment Option 3: N/A
- Overflow Loads: 1
- Telescope System: Full Power
- Max Tip Height: 184.5' (56.24m)
- Standard Lower Weights: 6,000lbs (2,722kg)
- Main Boom: Four Section Formed Boom
- Engine Make & Model: Cummins QSB 6.7L
- Length (min-max): 38.6'-120.1' (11.8m-36.6m)
- Horsepower: 232hp (173kW) @ 2,000rpm
- Max Line Speed No Load: 449fpm (137mpm)
- Base Rating: 80 Ton @ 9' (75mt @ 3m)
- Maximum Line Pull: 18,392lbs (8,342kg)
