- Shipping Weight: 1500 lbs
- Gauges: Hourmeter
- Overall Length: 72 in
- Transmission By-Pass: Control within pump to “Freewheel unit”
- Fuel Capacity: 1.75 gal
- Wheelbase: 50.75 in
- Engine Oil: 1.16 qts
- Engine: Honda 11 HP OHV Single Cylinder, Electric Start (in addition to pull start under cover), Low Oil Alert System, 12 Volt Battery.
- Steering: Automotive type, mechanical.
- Brakes: Dynamic w/mechanical band type parking brake on rear drum, adjustable brake lever.
- Overall Height: 58 in
- Drive System: Hydrostatic
- Water Tank: 25 gal
- Wall Clearance: .875 in
- Curb Clearance: 8.50 in
- Operating Weight (Full Ballast + Operator): 2400 lbs
- Safety Devices: Neutral Start Switch
- Hydraulic Fluid: 1 gal
- Overall Width: 38 in
- Turning Radius: 56 in
- Oscillation: 24 deg. Total
- Travel Speed: 0-5 mph
Drums
FRONT
|
Type |
Steel, machined surface w/ballast fill plug. |
|---|---|
|
Overall Width |
28 in. |
|
Diameter |
18 in. |
|
Shell Thickness |
500 in. |
REAR
|
Type |
Steel, machined surface w/ballast fill plug. |
|---|---|
|
Overall Width |
34.75 in. |
|
Diameter |
22 in. |
|
Shell Thickness |
500 in. |
Drum Spray System
|
Type |
Gravity w/dual brass ball valves. |
|---|---|
|
Tank |
Polyethylene, 25 gal. capacity, 3″ fill neck, cap w/safety chain, rear mount. |
|
Drum Scrapers |
Two steel scrapers, spring loaded. |
|
Drum Cocoa Mats |
One each drum, pivoting. |
Optional Equipment
|
Special Paint |
|---|
|
Back-up Alarm |
|
Voltage Gauge |
|
Vandal Protection Package (locking floor and dash cover) |
|
ROPS (Rollover Protection Structure) |
