DYNAPAC RAMMER — DR8D
From high-precision maneuvering to the roughest conditions, the four stroke low emission rammers from Dynapac lets you handle them all with ease. The hour & tacho-meter lets you stay connected for service planning & optimized use thus boosting productivity. Transport wheels and foot extensions ensure incredible flexibility.
Keep going no matter what! Reliable 4-stroke engine from Honda built specially for the hard hitting rammers are safe-guarded by all around metal covers.
STANDARD FEATURES
• Low vibration handle
• Fuel filtration system
• Dual stage air filtration system
• Recoil starter
• Loading aid rollers on Handle
• One-point lift
We reserve the right to change specifications without notice. Photos and illustrations do not always show standard versions of machines. The above information is a general description only, all information is supplied without liability.
- Engine - Emissions according to: Non-Regulated
- Dimensions - Length: 28.7 in
- Compaction - Impact force: 17.5 kN
- Dimensions - Height: 40.6 in
- Dimensions - Basic shoe width: 11.0 in
- Traction - Max. area coverage: 3,616.8 ft² /h
- Compaction - Vibration frequency: 600 – 720 vpm
- Engine - Rated power:
- Masses - Operating mass: 190 lbs
- Engine - Fuel tank capacity: 1 gal
- Masses - Net mass: 185 lbs
- Engine - Number of cylinders: 1
- Engine - Manufacturer/Model: Yanmar L48N
- Engine - Type : Air cooled diesel
- Traction - Max. working speed: 65.6 fpm
- Dimensions - Width: 13.8 in
