JCB 504-13 — TELESCOPIC HANDLER
BIG PERFORMANCE IN SMALL SPACES
The JCB 504-13 Loadall is compact, maneuverable telescopic handler with impressive lift capacity and reach for its size. Permanent 4-wheel steering and compact size enable an exceptionally tight turning circle for great maneuverability and handling in small spaces. This makes the 504-14 is ideally suited to working in greenhouses to parking garages, rental lots to construction sites.
PRODUCTIVITY & PERFORMANCE
A limited-slip differential is available for maximum traction on slippery surfaces by transferring drive from the spinning wheel to the stationary wheel.
• The 504-13 is equipped with a 39 hp JCB Perkins engine requires no aftertreatment and produces 120 lb-ft of torque at 1800 RPM.
• Four equal-sized wheels improve tractive effort for excellent loader performance, soft-ground flotation and ground clearance.
COMFORT & EASE OF USE
The JCB 504-13 telescopic handler has a large, spacious cab with a wide access door. The cab glass is tinted all round and the windshield and roof are laminated.
• JCB 504-13 controls are comfortable, precise and smooth thanks to single-lever electro servo controls with proportional auxiliaries.
• Telehandler operators can maneuver quickly and easily with directional shuttle changes possible via the shuttle lever on the steering column or the joystick-mounted shuttle switch.
VISIBILITY & SECURITY
The 504-13 Loadall telehandler features a low boom pivot point and slim outer boom for unmatched visibility to front and rear wheels on the right-hand side. Bystanders are further safeguarded by the standard-fit reversing alarm.
• Hose burst check valves (HBCVs) prevent the rams from collapse in the event of a hose failure.
• GPS tracking via JCB LiveLink telematics systems provides real-time location data, including geofencing alerts to let you know if your machine is being used beyond predefined boundaries.
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Specifications are subject to change without prior notice.
