The 75 ton crawler excavator offers the perfect combination of power and stability to handle a higher capacity in any application. Powered by Volvo’s Tier 4 Final compliant D16 engine, the heavy-duty EC750E delivers increased horsepower of 374 kW/502 hp, ensuring an extremely responsive operation for maximum productivity and profitability.

Gross power: 516 hp
Breakout force, SAE J1179 (Normal): 72,614 lbf
Bucket capacity: 4.3 - 6.7 yd³
Tear out force, SAE J1179 (Boost): 73,962 lbf
Tail swing radius: 13′ 7.0″ ft in
...at engine speed: 1,800 rpm
Operating weight: 162,040 - 166,008 lbs
Max. digging reach: 37′ 7.2″ ft in
Lifting capacity, along undercarriage: 67,184 lbs
Breakout force, SAE J1179 (Boost): 76,885 lbf
Max. digging depth: 23′ 7.9″ ft in
Overall width: 14′ 0.9″ ft in
Tear out force, SAE J1179 (Normal): 69,916 lbf
...at reach / height: 20 / 5 ft

Maximize machine uptime and performance for any job application with the reinforced heavy duty boom and arm.
With functions and properties ideally matched, Volvo attachments are an integrated part of the excavator for which they’re intended – delivering maximum productivity.
Rely on a top performance from the EC750E, featuring a powerful Volvo D16 engine for a fast and efficient operation.
The EC750E features superior digging force, particularly when working with hard and heavy materials.
Volvo uses the latest technology to monitor machine operation and status, giving you advice to increase your profitability. By having a Customer Support Agreement you are in control of your service costs.
