- Hydraulic System: Swing System Pressure : 3,133 psi
- Hydraulic System: Hydraulic Tank : 10.0 gal.
- Undercarriage and Slewing System: Maximum Arm Digging Force: 5,058 lbs.
- Dimensions: Max. Reach at Ground Level: 20' 1.7"
- Hydraulic System: Total Flow Rate : 36.9 gpm
- Hydraulic System: Working Pressure : 3,553 psi
- Engine: Displacement : 128 cu.in.
- Dimensions: Transport Length: 18' 3.7"
- Dozer Blade: Width - extended/retracted: 6' 5.6"
- Hydraulic System: Pumps: 2 variable, 2 gear
- Dimensions: Max. Digging Depth: 12' 9.5"
- Dimensions: Operating Weight with Cab: 12,247 lbs.
- Undercarriage and Slewing System: Maximum Bucket Breakout: 7,464 lbs.
- Dimensions: Max. Digging Height: 19' 10.6"
- Dimensions: Operating Weight with Canopy: 11,850 lbs.
- Hydraulic System: Oil Cooler: Standard
- Engine: Model: 4TNV86CT Tier IV
- Engine: Fuel Consumption : 1.35 gal./hr
- Dimensions: Parallel Offset Right: 2' 6.3"
- Engine: Type: Diesel
- Undercarriage and Slewing System: Track Length on Ground: 7' 4.4"
- Dimensions: Rear End Swing Radius: 3' 2.2"
- Dimensions: Max. Vertical Wall Digging Depth: 8' 4.8"
- Dimensions: Minimum Front Swing Radius: 6' 11.1"
- Dimensions: Max. Dump Height: 13' 3.4"
- Undercarriage and Slewing System: Track Type/Width: Rubber/15.7"
- Undercarriage and Slewing System: Ground Clearance: 13.6"
- Dimensions: Parallel Offset Left: 2' 2.8"
- Engine: Make: Yanmar
- Engine: Fuel Tank : 17.4 gal.
- Undercarriage and Slewing System: Slew Speed: 10 rpm
- Dimensions: Undercarriage Length: 8' 6"
- Dimensions: Blade Below Ground/ w/angle blade: 1' 10.4" / 1' 9.3"
- Undercarriage and Slewing System: Maximum Drawbar Pull: 12,544 lbs.
- Dimensions: Transport Height: 8' 4"
- Undercarriage and Slewing System: Number of Rollers per Side (Track/Idle): 4/1
- Undercarriage and Slewing System: Gradability: 20°
- Dimensions: Ground Clearance: 1' 1.6"
- Undercarriage and Slewing System: Travel Speed - dual: 1.4/2.6 mph
- Dimensions: Overall Base Width: 6' 6.3"
- Dozer Blade: Height: 15.7"
- Dimensions: Track Width: 1' 3.7"
- Undercarriage and Slewing System: Ground Pressure - Cab/Canopy: 4.4/4.3 psi
- Engine: Net Power @ rpm: 44.9 hp @ 2400
- Angled crawler frame reduces soil buildup on the undercarriage, extending the life of rollers and tracks.
- Two large, rear doors open easily to expose the battery, engine oil, air filter and cooling system.
- Heavy-duty sliding cylinder guards protect exposed cylinder rods from damage.
- Work lights and integrated boom light enhances the operator’s view after dark.
- Standard auxiliary proportional hydraulics give the operator infinitely variable control of the hydraulic flow.
- Auto Deceleration lowers the engine speed to idle, reducing the noise and emissions levels when the hydraulic movement has not occurred for more than four seconds. This increases fuel economy and lowers operating costs.
- Precision welded boom is constructed with thick side plates that are reinforced by contoured transition plates.
- Two variable pumps and two gear pumps combine oil and redirect the flow to where it is needed, allowing for simultaneous operation without loss of power.
- One-way auxiliary functions can be controlled by a foot pedal or joystick buttons, allowing optimal control of high-flow attachments such as compactors or breakers.
- Pilot operated joystick controls are operated by simple wrist movements, reducing fatigue during a long workday.
- Smooth operation, even while using the boom and arm during turning.
- The access panel beneath the operator’s seat easily opens to reveal the starter motor, fuse panel, alternator and fan belt.
- Long tracks provide a smoother ride over rough terrain.
- Easy-starting, even in cold weather without the need for block heaters or starting fluid.
- Open canopy for easy entry and exit.
- Optional cab enclosure with heat or heat/air-conditioning system provides protection in extreme weather conditions.
- A cover on top of the unit on the right side allows access to the fuel supply and a handy tool storage tray.
- The right-hand side cover is easily removed with just two bolts. Remove the top right hand side to easily clean behind the radiator.
- Proven technology provides reliable operation and a fuel efficient system.
- Two-way and one-way auxiliary flow valve with direct-to-tank bypass valve feature is standard equipment.
- Yanmar Tier IV certified turbo charged, diesel engine with 44.9 hp provides excellent balance in power and fuel conservation.
- The operator can easily select from ISO or standard operating control patterns with the flip of a mechanical lever.
- Large travelling pedals are easy to press and allow confident, reliable work.
- Tracks are short-pitched to reduce wear, fatigue and damage.
- Staggered tread and mandrel design combined with shorter track pitch reduces vibration.
- Excellent visibility in all directions allows safe and efficient operation. Rear mirror provides a view of the back and side of the machine for additional safety.
- Large cab offers state-of-the-art controls, digital display and excellent visibility.
- Auxiliary hydraulic shut-off valve, tubing and hoses with flat faced coupler connections are standard equipment.
- Reliable single pin boom mount design for optimal durability and component life.
- ECO Mode can be activated from the cab with a switch. When activated, the engine speed is reduced by 10%, reducing fuel consumption for lowered operating costs.
- Digital Operator Interface shows real time system information, service reminders, and 90 days of operating history.
- Hydraulic system is designed to enhance engine performance, resulting in a more efficient system.
- Adjustable suspension seat and armrests provide personalized comfort.
- Integrated boom light illuminates the work area and allows for safe and effective operation after dark.
