INCREASE YOUR PRODUCTIVITY AT EACH LOAD
Get the most out of your investment with the fuel-efficient R100 rigid dumper, your partner for all mining and quarrying applications. Featuring a ROPS/FOPS-certified cab, proven safety systems and straightforward service access, the R100 rigid dumper from Volvo is safe from the inside out.
- PAYLOAD CAPACITY: 105 sh tn
- BODY VOLUME, SAE 2:1 HEAP: 79 yd³
- GROSS POWER: 1,050 hp
- Enjoy superior ride quality and comfort in the robust R100 rigid dumper, equipped with variable hydraulic wishbone-type suspension and viscous-mounted cab for minimal ground impact and vibrations. The responsive, low-effort steering system and geometry, combined with the suspension, optimizes maneuverability by minimizing lean on tight corners. With the R100 rigid dumper, heavy-duty hauling has never felt so easy.
- There’s no compromise when it comes to safety. That’s why all machine systems on the R100 rigid dumper, such as the easily accessible emergency shutdown switches, have been designed and verified to protect the safety of you and your crew. From the ROPS/FOPS-certified cab, experience superb visibility, enhanced by Volvo Smart View, an integrated feature that helps you keep an eye on the surrounding job site traffic.
- The robust and reliable R100 rigid dumper delivers superior, long lasting performance. Engineered with uptime in mind, the heavy-duty dumper is simple and uncomplicated in its design, and purpose-built to achieve optimum productivity shift after shift, day in and day out.
- Move more with less fuel thanks to the latest technology built-into the R100 rigid hauler. Volvo Dynamic Shift Control delivers a premium drivetrain performance and also incorporates Eco Shift Mode, which defaults to the most efficient shift schedule when working on lighter applications. The auto-idle engine shutdown and optional gear sensitive On-Board Weighing further enhance fuel savings and reduce unnecessary engine wear.
- Offering a true 95-tonne payload, the R100 rigid dumper is designed to do more. Thanks to its exhaust-heated V-shaped body, the 60m3 capacity dumper ensures optimum load retention and minimal material carry-back. For long lasting performance, the body is manufactured from high impact and high abrasion resistant steel. Enhance productivity with our 10-10-20 payload policy.
TECHNICAL SPECIFICATIONS FOR R100
|
Product technical designation |
R100E |
|---|---|
|
Payload capacity |
105Â sh tn |
|
Body volume, SAE 2:1 heap |
79 yd³ |
|
Net weight |
153,777Â lbs |
|
Gross weight |
363,216Â lbs |
|
Engine |
Cummins QST30 (Tier 4 final certified) |
|
Gross power |
1,050Â hp |
|
Engine speed at max engine torque |
2,100Â rpm |
|
Max SAE J1349 gross torque |
3,416Â lbf ft |
|
…at engine speed |
1,300Â rpm |
|
Max speed |
31.1Â mph |
