TOWMASTER T-24LP — DECK-OVER TRAILER

The premium line of Towmaster® deck-over trailers has proven to offer durability, longevity and style that other brands try to emulate. Our build quality and design creates a trailer that is easy to own and easy to maintain. They are built on our famous I-Beam main frame with a 20-foot deck and self-cleaning angle iron beavertail. Two-way spring-assist ramps are standard.

STANDARD EQUIPMENT

• Adjustable hitch height

• 7-pole round electrical plug

• Weather resistant sealed modular wiring

• Grommet mounted LED lights

• Registration holder

• Rust inhibiting primer

• Durable, rust inhibiting top coat! Die-cut UV resistant vinyl decals

• D.O.T. approved conspicuity tape

• Mud flaps

• Trailer color: Equipment black

• Ramp color: Equipment Red

OPTIONAL EQUIPMENT

• Gooseneck

• 25K two-speed parking jack

• Dual parking jacks

• Additional deck length

• Additional tie-downs

• Rub rail with stake pockets

• 12K electric winch

• Spare tire and wheel mount

• Spare tire and wheel

• Tire upgrade (load range G)

• Double-break beavertail

• Several beavertail options

• Color options: Construction Yellow, Equipment Red, Blue, Charcoal

• Galvanizing

Similar models may be shown in addition to the featured model. Equipment may be shown with options. Manufacturer reserves the right to change models and specifications as they see fit.

  • Suspension / Tires - Brake Size : 12.25" x 5" | 311 x 127 mm
  • Capacity / Dimensions - Deck Height - Loaded: 32" | 813 mm
  • Suspension / Tires - Wheel Bolt Pattern: 8-bolt
  • Suspension / Tires - Electric Brakes: Standard
  • Suspension / Tires - Hubs: Oil Bath
  • Suspension / Tires - Axle Capacity - Each: 12,000 lbs | 5443 kg
  • Capacity / Dimensions - GVWR : 31,300 lbs | 14,197 kg
  • Frame / Ramps - Two-Way Spring Assist: Standard
  • Capacity / Dimensions - Overall Length : 31'4" | 9550 mm
  • Frame / Ramps - Channel Side Rails : 8" | 203 mm
  • Suspension / Tires - Tires / Load Range Rating: 235 | 85R16 / E
  • Frame / Ramps - Wood Protectors: Standard
  • Tongue - Pintle Ring : Standard
  • Frame / Ramps - One-Piece Cold-Formed Frame Rails: Standard
  • Frame / Ramps - Headboard: 5.5" | 140 mm
  • Frame / Ramps - Main Beam: W8, x 17 Gr. 50
  • Capacity / Dimensions - Overall Width : 8'6" | 2591 mm
  • Capacity / Dimensions - GAWR : 24,000 lbs | 10,866 kg
  • Frame / Ramps - Deck Material: 2” nom. White Oak
  • Frame / Ramps - Forged D-Ring Tie Downs - Total | Side: 8 | 4
  • Suspension / Tires - Air Brakes - Full ABS Modulated, Park Brake All Axles : Optional
  • Suspension / Tires - Hub Piloted Budd-type Wheels : 16" x 6" | 406 x 152 mm
  • Suspension / Tires - Hutchens Spring Suspension: Standard
  • Capacity / Dimensions - Deck Length : 20' | 6096 mm
  • Tongue - Storage Tray with Lid: Standard
  • Frame / Ramps - Crossmembers: 3” Jr I-beam
  • Frame / Ramps - Beavertail (angle-degrees): 5' | 1524 mm (12)
  • Capacity / Dimensions - Capacity Rating : 24,000 lbs | 10,866 kg
  • Tongue - High-Tensile Safety Chain : 1/2" Grade 70
  • Tongue - Bolt-on Drop-Leg Parking Jack: 12K
  • Capacity / Dimensions - Approx. Weight : 7,300 lbs | 3311 kg
  • Frame / Ramps - Ramps : 5' x 21" | 1524 x 533 mm
  • Tongue - Tongue Length: 5'2" | 1575 mm
  • Suspension / Tires - No. of Axles: 2
  • Suspension / Tires - Axle Spread : 49" | 1245 mm
