TOWMASTER T-50 — DECK-OVER TRAILER
These premium Towmaster® deck-over trailers are built more durable and more stylish to provide a great looking trailer that will last a long time. They are great for hauling heavy equipment of all types. If you need a lower profile trailer, the T-50LP gives you an extra 2-inches and lower loading angle. Two-way spring-assist ramps and wood protectors are standard.
STANDARD EQUIPMENT
• Adjustable hitch height
• 7-pole round electrical plug
• Weather resistant sealed modular wiring
• Grommet mounted LED lights
• Registration holder
• Rust inhibiting primer
• Durable, rust inhibiting top coat
• Die-cut UV resistant vinyl decals
• D.O.T. approved conspicuity tape
• Mud flaps
• Trailer color: Equipment black
• Ramp color: Equipment Red
OPTIONAL EQUIPMENT
• Dual parking jacks
• Additional deck length
• Additional tie-downs
• Rub rail with stake pockets
• 12K electric winch
• Tire upgrade (G-rated)
• Air-Lift front axle
• Spare tire and wheel mount
• Spare tire and wheel
• Double-break beavertail (not on LP)
• Several beavertail options
• Color options: Construction Yellow, Equipment Red, Blue, Charcoal
• Galvanizing
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Manufacturer reserves the right to change models and specifications as they see fit.
- Capacity / Dimensions - Deck Length : 24' | 7315 mm
- Capacity / Dimensions - Deck Height - Empty: 31.5" | 800 mm
- Capacity / Dimensions - Overall Length : 35'4" | 10,770 mm
- Frame / Ramps - Channel Side Rails : 8" | 203 mm
- Frame / Ramps - One-Piece Cold-Formed Frame Rails: Standard
- Suspension / Tires - Hub Piloted Budd-type Wheels : 17.5 "x 6.75" | 445 x 171 mm
- Tongue - High-Tensile Safety Chain : 5/8" Grade 80
- Capacity / Dimensions - GAWR : 54,480 lbs | 24,712 kg
- Tongue - Storage Tray with Lid: Standard
- Capacity / Dimensions - Approx. Weight : 10,600 lbs | 4808 kg
- Suspension / Tires - Tires / Load Range Rating: 215/75R17.5 | H
- Frame / Ramps - Headboard : 5.5" | 140 mm
- Suspension / Tires - Hubs: Oil Bath
- Frame / Ramps - Two-Way Spring Assist: Standard
- Suspension / Tires - Wheel Bolt Pattern: 8-bolt
- Tongue - Tongue Length : 5'2" | 1575 mm
- Tongue - Pintle Ring : Standard
- Tongue - Bolt-on Drop-Leg Parking Jack: 25K
- Capacity / Dimensions - Overall Width : 8'6" | 2591 mm
- Frame / Ramps - Wood Protectors: Standard
- Frame / Ramps - Deck Material: 2” nom. White Oak
- Frame / Ramps - Ramps : 5' x 21" | 1524 x 533 mm
- Frame / Ramps - Main Beam: W10, x 26 Gr. 50
- Frame / Ramps - Beavertail (angle-degrees): 5' | 1524 mm (12)
- Suspension / Tires - Axle Spread : 49" | 1245 mm
- Suspension / Tires - No. of Axles: 3
- Suspension / Tires - Hutchens Spring Suspension: Standard
- Suspension / Tires - Brake Size : 12.25" x 7.5" | 311 x 191 mm
- Frame / Ramps - Forged D-Ring Tie Downs : Total 8 | 4 Side
- Capacity / Dimensions - Capacity Rating : 50,000 lbs | 22,680 kg
- Suspension / Tires - Air Brakes - Full ABS Modulated, Park Brake All Axles : Standard
- Frame / Ramps - Crossmembers: 3” Jr I-beam
- Capacity / Dimensions - GVWR : 60,600 lbs | 27,488 kg
- Suspension / Tires - Axle Capacity - Each : 22,500 lbs | 10,206 kg
