TOWMASTER T-120DTG — DETACHABLE GOOSENECK (AIR-PIN)
The Towmaster® detachable gooseneck trailers are a state-of-the-art design with modular frame construction. This detachable gooseneck trailer offers more convenient features to make loading or unloading quick and easy. The fit and finish is unmatched as the entire trailer is pre-painted before assembly and decking for a professional, clean look. The Towmaster detachable is completely designed and built at our factory, so you can be sure you are getting a genuine quality Towmaster Trailer.
STANDARD EQUIPMENT
• S.A.E. king pin set at 16”
• Weather resistant sealed modular wiring
• Grommet mounted LED lights
• Registration holder
• Rust inhibiting primer
• Durable, rust inhibiting top coat
• Die-cut UV resistant vinyl decals
• D.O.T. approved conspicuity tape
• Mud flaps
• Trailer color: Equipment black
OPTIONAL EQUIPMENT
• Longer swing-clearance lengths
• Gooseneck fenders
• Self-contained hydraulic unit
• Dual hydraulic system
• Tapered deck
• Additional deck length
• Wide deck
• Bucket plate
• Several ramp options
• Several wheel options
• Booster and Flip-Axle options
• Suspension and brake options
• Color options: Construction Yellow, Equipment Red, Blue, Charcoal
Similar models may be shown in addition to the featured model. Equipment may be shown with options. Manufacturer reserves the right to change models and specifications as they see fit.
- Gooseneck - Wet Line Hydraulic System: Standard
- Capacity / Dimensions - Deck Length : 24' | 7315 mm
- Gooseneck - Length : 12'10" | 3912 mm
- Main Deck / Rear Trunnion - Main Beam (T1 Flange) (in): 16 Fabricated
- Gooseneck - Swing Clearance : 108" | 2743 mm
- Main Deck / Rear Trunnion - Stinger Reinforcemen: Optional
- Suspension / Tires - Axle Capacity - Each: 25,000 lbs | 11,340 kg
- Suspension / Tires - Wheel Bolt Pattern: 10-bolt
- Suspension / Tires - Axle Spread : 55" | 1397 mm
- Gooseneck - Air-Pin Deck Lock: Standard
- Main Deck / Rear Trunnion - Front Flip-up Ramps: Standard
- Main Deck / Rear Trunnion - Flip Axle Mount Brackets: Standard
- Capacity / Dimensions - Overall Width : 8'6" | 2591 mm
- Main Deck / Rear Trunnion - Approach Bolster: Standard
- Suspension / Tires - Brake Size : 16.5" x 7" | 419 x 178 mm
- Main Deck / Rear Trunnion - Number of Tie-Downs : 12 Total | 6 Side
- Capacity / Dimensions - Deck Height - Fully Loaded : 24" | 610 mm
- Main Deck / Rear Trunnion - Crossmembers : 10" Deep x 4" Flange
- Main Deck / Rear Trunnion - Tie Downs: Forged D-rings
- Main Deck / Rear Trunnion - Swing-out Outriggers: Standard
- Main Deck / Rear Trunnion - Trunnion Open Boom Well: Standard
- Suspension / Tires - Meritor Axles - number of axles: Standard | 3
- Capacity / Dimensions - Capacity Rating in 16ft : 120,000 lbs | 54,431 kg
- Main Deck / Rear Trunnion - Outside Rails (T1 Flange) (in): 14 Fabricated
- Main Deck / Rear Trunnion - HD Removable Swing-out Outriggers: Optional
- Main Deck / Rear Trunnion - Supporting Bolsters Between Wheels: Standard
- Suspension / Tires - 22.5x8.25 Budd-type Wheels: Standard
- Suspension / Tires - Oil Bath Hubs: Standard
- Main Deck / Rear Trunnion - Outside Oak Deck Full 2”: Standard
- Main Deck / Rear Trunnion - Fixed Approach: Optional
- Main Deck / Rear Trunnion - Diamond Cut-outs: Optional
- Capacity / Dimensions - Capacity Rating : 120,000 lbs | 54,431 kg
- Gooseneck - Fifth-Wheel Deck Lock: N/A
- Main Deck / Rear Trunnion - Self-Aligning Locking Fifth-Wheel : Standard
- Suspension / Tires - Forged Alloy Spindles: Standard
- Gooseneck - Twin Five-Position Load Block: Standard
- Gooseneck - Greaseable Pivot Points: Standard
- Suspension / Tires - Tire Size - all Load Range Rating H: 275/70R x 22.5
- Capacity / Dimensions - Overall Length : 50'10" | 15,494 mm
- Suspension / Tires - Poly Mud Flaps: Standard
- Capacity / Dimensions - Approx. Weight : 19,500 lbs | 8845 kg
- Suspension / Tires - Air Brakes: Standard
- Suspension / Tires - Wheels Hub Piloted: Standard
- Suspension / Tires - Air Suspension: Standard
