From moving sand and gravel to salt and snow, the L918F compact wheel loader is suited for all seasons — it’s the economical compact loader option perfect for any small landscaping, bulk and material handling, or snow removal jobs. Its skid-steer-style coupler makes it a versatile loader fit for multiple attachments. And whether you need to operate at faster speeds to clear snow, or at a slower pace for jobs that aren’t time-sensitive, the L918F loader provides the perfect balance with ground speeds up to 15 mph (24 kph). Its low-maintenance engine and basic features make it a simple, compact loader at an affordable price.
SDLG’s L918F compact wheelloader has a 1.0 yd3 (0.8 m3) general purpose bucket mounted to its skid-steer-style coupler, placing it in the compact loader category but with the versatility of skid-steer-style attachments. The L918F front end loader has a rated load of 2.0 tons (1.8 metric tons), a Deutz tier 4 final certified engine, skid-steer-style hydraulic quick coupler, and full powered third function hydraulics.
- Manual powershift transmission provides precise gear selection
- Joystick with integrated directional control switch allows for fingertip shifting and more intuitive loader control, and a separate third-function lever powers attachment hydraulics
- 12-month/2,000-hour warranty with optional extended coverages available
- General purpose skid-steer-style bucket with reversible bolt on cutting edges provides easy loading and longer bucket edge life
- SDLG conventional axles with air-cooled, dry-disc brakes make servicing simple
- Skid-steer-style coupler with in-cab control simplifies attachment changes for ultimate versatility
- Deutz 3.6-liter, Tier 4f certified engine is designed for lower maintenance and features automatic, in-the-background regeneration with no DEF or DPF requirements
- Operator cab features A/C, AM/FM and USB radio, and is ROPS/FOPS approved with excellent 360-degree visibility for a ready-to-work operator environment
SPECIFICATIONS
|
Engine Model |
Deutz TCD3.6 L4 (Tier 4f) |
|
|
Max Power |
74 hp @ 2300 rpm |
55 kW @ 2300 rpm |
|
Max Torque |
288 lbfft @ 1300 rpm |
390 Nm @ 1300 rpm |
|
Bucket Capacity |
1.0 yd3 |
0.8 m3 |
|
Rated Load |
4000 lbs |
1,800 kg |
|
Full Turn Tipping Load |
7,940 lbs |
3,600 kg |
|
Breakout Force |
8,543 lbs |
38 kN |
|
Hydraulic System Flow, Max (System & 3rd function) |
31 gpm @ 2030 psi |
|
|
Max Dump Height |
8’ 0” |
2,420 mm |
|
Standard Tire Size |
405 / 70-20 |
|
|
Turning Radius, Outside Bucket |
17’ 6” |
5,340 mm |
|
Turning Radius, Rear Tire |
15’ 8” |
4,770 mm |
|
Dimensions with Bucket (LxWxH) |
19’ 2” x 7’ 0” x 9’ 7” |
5850 x 2140 x 2920 mm |
|
Operating Weight |
14,990 lbs |
6,800 kg |
